Bokeh GRX Di2 £3,995.00

Size

Colour

  1. Element Grey
  2. Flare Orange
  3. Filter Green

1x or 2x

  1. 1x
  2. 2x

Bokeh GRX Di2

GRX Di2 is Shimano's fully electronic adventure-riding specific groupset. Designed with a range of unique performance features and ergonomics developed over several years to make adventure riding as fast and comfortable as possible.

Our builds are available with 1×11 or 2×11 cranksets, both using adventure/bikepacking tuned ratios, and the latest clutched RX-817 Di2 derailleurs to match.

Complete bike images and details will be updated as soon as possible. Please contact us for more details.

Features

  • GRX crankset with gravel specific gearing ratios.
  • RD-815 DI2 Shadow RD+ clutched rear mech.
  • 1x = £3995, 2x = £4195
  • 1X: Lightweight M8000 11-42 Cassette / 2X: R800 11-34 Cassette
  • Unique Mason MultiPort adaptable internal routing.
  • Available in 1x or 2x.
  • Full Shimano GRX 815, 11speed, electronic Di2 groupset.
  • Dedacciai, custom formed, triple-butted performance Aluminium frame with Mason Parallax2 full carbon Thru-Axle fork.
  • Shimano GRX Di2: The first electronic groupset designed specifically for adventure and exploration riding.

Technical info

Select size


Dimensions
(mm unless specified)
A > SEAT TUBE C/T 500
B > SEAT TUBE C/C 453
C > BB DROP 75
D > REAR CENTRE 435
E > TT EFFECTIVE 519.9
F > TT ACTUAL 503.9
G > STACK 537.9
H > REACH 363.5
I > STAND-OVER 764.1
J > OFFSET 50
K > TRAIL 75.3
L > FORK CROWN HEIGHT 398
M > HEAD ANGLE 70
N > HEAD TUBE LENGTH 115
O > SEAT TUBE ANGLE 74
P > WHEELBASE 1013.7
Q > HANDLEBAR (OUTSIDE DIMENSION) 42
Dimensions
(mm unless specified)
A > SEAT TUBE C/T 520
B > SEAT TUBE C/C 473.0
C > BB DROP 75
D > REAR CENTRE 435
E > TT EFFECTIVE 535.9
F > TT ACTUAL 520.3
G > STACK 554
H > REACH 374.0
I > STAND-OVER 781.8
J > OFFSET 50
K > TRAIL 72
L > FORK CROWN HEIGHT 398
M > HEAD ANGLE 70.5
N > HEAD TUBE LENGTH 130
O > SEAT TUBE ANGLE 74
P > WHEELBASE 1021.8
Q > HANDLEBAR (OUTSIDE DIMENSION) 42
Dimensions
(mm unless specified)
A > SEAT TUBE C/T 540
B > SEAT TUBE C/C 493.5
C > BB DROP 73
D > REAR CENTRE 435
E > TT EFFECTIVE 551
F > TT ACTUAL 534.4
G > STACK 568.1
H > REACH 376.2
I > STAND-OVER 799.4
J > OFFSET 50
K > TRAIL 68.7
L > FORK CROWN HEIGHT 398
M > HEAD ANGLE 71.0
N > HEAD TUBE LENGTH 145
O > SEAT TUBE ANGLE 73
P > WHEELBASE 1028.4
Q > HANDLEBAR (OUTSIDE DIMENSION) 44
Dimensions
(mm unless specified)
A > SEAT TUBE C/T 560
B > SEAT TUBE C/C 513.7
C > BB DROP 73
D > REAR CENTRE 435
E > TT EFFECTIVE 561.4
F > TT ACTUAL 546.3
G > STACK 579.5
H > REACH 383.4
I > STAND-OVER 814.8
J > OFFSET 50
K > TRAIL 65.4
L > FORK CROWN HEIGHT 398
M > HEAD ANGLE 71.5
N > HEAD TUBE LENGTH 155
O > SEAT TUBE ANGLE 73
P > WHEELBASE 1034.4
Q > HANDLEBAR (OUTSIDE DIMENSION) 44
Dimensions
(mm unless specified)
A > SEAT TUBE C/T 580
B > SEAT TUBE C/C 534.1
C > BB DROP 70
D > REAR CENTRE 435
E > TT EFFECTIVE 580.8
F > TT ACTUAL 567.2
G > STACK 587.9
H > REACH 395.2
I > STAND-OVER 831.0
J > OFFSET 50
K > TRAIL 62.1
L > FORK CROWN HEIGHT 398
M > HEAD ANGLE 72
N > HEAD TUBE LENGTH 165
O > SEAT TUBE ANGLE 72.5
P > WHEELBASE 1045.4
Q > HANDLEBAR (OUTSIDE DIMENSION) 46
Dimensions
(mm unless specified)
A > SEAT TUBE C/T 60
B > SEAT TUBE C/C 554.2
C > BB DROP 70
D > REAR CENTRE 435
E > TT EFFECTIVE 590.7
F > TT ACTUAL 577.1
G > STACK 607.0
H > REACH 399.1
I > STAND-OVER 850.0
J > OFFSET 50
K > TRAIL 62.1
L > FORK CROWN HEIGHT 398
M > HEAD ANGLE 72
N > HEAD TUBE LENGTH 185
O > SEAT TUBE ANGLE 72.5
P > WHEELBASE 1055.4
Q > HANDLEBAR (OUTSIDE DIMENSION) 46
Dimensions
(mm unless specified)
A > SEAT TUBE C/T 620
B > SEAT TUBE C/C 574.7
C > BB DROP 70.0
D > REAR CENTRE 435
E > TT EFFECTIVE 600.5
F > TT ACTUAL 585.8
G > STACK 630.7
H > REACH 401.4
I > STAND-OVER 871.7
J > OFFSET 50
K > TRAIL 62.1
L > FORK CROWN HEIGHT 398
M > HEAD ANGLE 72
N > HEAD TUBE LENGTH 210
O > SEAT TUBE ANGLE 72.5
P > WHEELBASE 1065.5
Q > HANDLEBAR (OUTSIDE DIMENSION) 46

This page gives you some guidelines based on rider height, but these are only a starting point for a proper bike fitting. The dimensions show the extremes of useable frame size based on height and the rider size range is very similar for all our frames with 6 standard sizes [50-60cm]. InSearchOf sizing: We would recommend selecting one size down from your normal 'road' frame size. For example, if you would normally ride a 54cm then a 50cm InSearchOf is probably best for you.

Sizing chart

Fitting a bike to a rider is an important process, this information is a start to the process but it’s not really possible to give 100% accurate fitting instructions online.

Humans are odd shapes, each person’s physical dimensions: arm, torso, femur length, level of flexibility even skill level are very different. This means that there will invariably be different frame size requirements, even for people of the same height and inseam.

We are experienced in sizing and geometry, so of course we will be on the end of the phone or email to help and advise, but I would always recommend having a proper bike fit done before committing, especially if you feel like you may be between sizes.

We have specified bar width, stem length, and crank length to be the best fit for the majority of riders on each frame size, but we can sometimes make adjustments to this at your request. Please contact us for advice, or just let us know your sizing requirements in the comments box at the checkout page.

We'll set-up the front brake to be operated by the Right Hand lever for all UK destinations. For destinations outside of the UK, we'll set-up your bicycle with Front Brake/Left Hand as standard. It's no problem for us to set-up the brakes in your own chosen configuration, please state in 'Order Notes' how you like 'em.

If you are between sizes, it’s probably best to go with the smaller size. It’s easier to make a smaller frame fit a little larger than vice versa.

Specifications

Our frame sets deserve the best components, so we put a great deal of thought into the mix of parts used for each bike build. Bars, stem and crankset are sized to match frame size choice. See Geometry chart for component sizing.

Frame Dedacciai custom-shaped performance Aluminium.
Fork Mason Parallax2 full carbon Thru-Axle fork.
Headset DEDA Low profile integrated headset.
Colours Element Grey. Flare Orange. Filter Green
Bike Weight 54cm 9.2kg.
Sizes 50, 52, 54, 56, 58, 60, 62.
Shifting Shimano GRX-815 Di2 Shifting.
Chainset Shimano GRX-810 1x (42T) / 2x (48/31)
Cassette Shimano M8000 11-42. / CS800 11-34
Chain Shimano HG701 11 Spd.
Braking Shimano GRX-810 Hydro Calipers.
Tyres Choice of Schwalbe, Panaracer, WTB.
Wheels HUNT Four Season Gravel Disc / Mason X HUNT 650B AdventureSport Disc. Other models available.
Bar Tape Fabric Hex tape.
Handlebar Deda Gravel100
Clamp MASON Macro alloy ultralight.
Seatpost MASON Penta carbon, microadjust.
Saddle Fabric Scoop, Shallow, Mason Custom.
Stem DEDA Zero100.
